Description
Specs
Suspension –Custom-tuned, heavy-duty KKE Inverted (Upside Down) Hydraulic Front Fork
Brakes – Bilateral 4-piston hydraulic disc brake system
Dimension – 72.83 *30.71 *42.52in
Wheel Base – 49.41in
Seat Height– 32.68in
Curb Weight – 59kg
Carrying Capacity – 100kg
Ground Clearance – 10.63in
Front Fork Travel – 7.87in
Rear Shock/Wheel Travel– 3.35in
Max. Torque (on wheel) – 295nm
Power System – PMSM MTPA/MTPV FOC Controller
Maximum Power(Motor)– 10kW
Riding Mode– S mode/E mode
Assistance Functions – 5-level REGEN / 2-level SWC / Auto hold function
Battery Type– 72V/35Ah
Primary Belt System– Primary belt transmission
secondary chain transmission
secondary chain transmission
Top Speed – 80km/h
Max Range – 75km@40km/h
Charge Time –（20%-80%) – 2.15h
Tires Type – Front:70/100-19 – Rear: 3.00-18
Acceleration – 1.29s（0-30km/h
Frame Material – Forged aluminium alloy double cradle
Swingarm Type – Forged aluminium alloy
GPS Terminal – APP connection(T-box)
Safety function – Tilt protection, Brake priority setting Override protection, Power system high/low temperature protection, High/low voltage protection, Overcurrent protection etc, Side stand protection
Tilt Protection – Electronic gyroscope
Max load– 100kg
